79-00-120 Oil Level Sensor
79-00-121 Removal of the Oil Level Sensor
1. Disconnect the electrical connector (MOK).
2. Disconnect the screws.
3. Remove the cover and the oil-level sensor.
4. Remove and fit the oil-level-sensor.
79-00-122 Installation of the Oil Level Sensor
1. Use a new O-ring.
2. Lubricate the O-ring with oil.
3. Insert the oil-level-sensor.
4. Push down the sensor with light pressure in the oil sump [1].
5. Put the cover in place above the oil level sensor.
6. Screw the oil level sensor together with the cover down with 5 Nm using Loctite 243.
When using Loctite, make sure, that the thread is free of grease and apply only a thin
film of Loctite.
7. Connect the cable (MOK).
8. Perform an engine ground run according to Chapter 71-00-03.
9. After the ground run inspect oil system for leakage.
Fig. 79 - 18
