Austro Engine AE300 - Mounting Backbones

Maintenance Manual
E4.08.04
Issue date: 14-Apr-2015
Page: 71-9
Revision no: 25
71-50-60 Mounting Backbones
Fig. 71 - 2
Use the screw to fix the clamp and torque it with 10 Nm (see Fig. 71-3)
Fig. 71 - 3
Use the screw of the engine fastener to fix the clamp and torque it with 12 Nm
(see Fig.71-3).
09
06
12
06
09
12
