Austro Engine AE300 Service Manual

Maintenance Manual
E4.08.04
Issue date: 14-Dec-2015
Page: 05-11
Revision no: 26
Activities/Services Interval
100 h
12 Months
300 h
600 h
900 h
Chapter
Check
Change
Check
Change
Check
Change
Check
Change
refer to
ENGINE
Zonal Inspection
●
05-20-20
Injector Cover
●
05-20-21
Timing chain
●
(1)
(2)
(1)
05-20-22
Cylinder head
●
05-30-04
(1)
on demand
(2)
check if timing chain was not replaced during 600 hours inspection
05-30-01 Gearbox
Conduct a visual inspection of the gearbox every 100 operation hours. Inspect the gearbox for:
● Leakages at the housing and input shaft sealing ring
For removal and installation of the gearbox refer to Chapter 85-10-10.
For engine model E4P: Only use Gearbox E4A-70-000-000 Rev.110 or higher for
replacement.
05-30-02 Injectors
Remove and install the injectors according to Chapter 73-00-10.
05-30-03 Turbo Charger
Remove the exhaust pipe and the intake air hose from the turbo charger according to chapter
78-00-11 step 1 and 2.
Conduct an inspection of the turbo charger to the following:
● Perform a visual inspection of the turbo charger for:
– Oil leakages
– Mechanical wear and damages at the compressor and turbine blades
– Significant wear and grooves at the air intake and exhaust port
● Check the axial play of the shaft
Install the intake air hose and the exhaust pipe according to chapter 78-00-12 step 12 to step 16.
For removal and installation of the turbo charger refer to Chapter 81-00-10.
