5. Screw down the injector cover with 9 Nm.
6. Install the maintenance lid – refer to Chapter 85-00-15.
7. Attach the breather line to the injector cover - refer to the applicable Aircraft
Maintenance Manual.
8. Install the oil-separator return line - refer to Chapter 79-00-92.
9. Perform an engine ground run according to Chapter 71-00-03.
85-00-15 Installation of the Maintenance Lid
1. Cover the overlapping area at the injector cover with silicone – refer to Fig. 85 -9.
2. Put the maintenance lid at the provided opening at the injector cover and move it
thus the holes at the lid are coaxial with the threads at the injector cover.
3. Fix the lid screws with a torque of 3 Nm.
4. Secure the screw with a safety wire – refer to Fig. 85 – 4.
Figures for Chapter 85-00-14 to 85-00-15
Fig. 85 - 6
Fig. 85 - 7
