Austro Engine AE300 Service Manual

Maintenance Manual
E4.08.04
Issue date: 14-Apr-2015
Page: 71-8
Revision no: 25
71-50-40 Material and saving material for the Engine Wiring Harness
Pos
Part number
Description
St
Torque specification
Tool
01
E4A-90-000-000
Engine wiring harness
1
02
E4A-90-000-801
Hex-head screw with
tooth lock M6x10
1
6 Nm
03
DIN3016-W1-DM
12x15
Clamp
1
12 Nm
04
DIN3016-W1-DM
6x15
Clamp
2
5 Nm
05
DIN3016-W1-
DM8x15
Clamp
2
6 Nm
06
E4A-90-000-802
Hex-head screw with
tooth lock M6x16
2
10 Nm
07
E4A-90-000-803
Hex-head screw with
tooth lock M8x16
1
12 Nm
08
E4A-90-100-801
Cable strap 100 x 2,5 mm
60
09
DIN3016-W1-
DM15x15
Clamp
1
10
E4A-90-100-808
Cable strap with
EdgeCLip
1
11
DIN3016-W1-
DM10x20
Clamp
2
12
DIN3016-W1-
DM13x20
Clamp
1
12 Nm
13
E4A-90-100-805
Cable strap 340x4,5
2
14
E4A-90-100-810
Mesh tube
ø 8 mm x195 cm
15
E4A-90-100-811
Mesh tube
ø 13 mm x 100 cm
Mounting of mesh tube pos.14 and pos.15 is shown on several Figures.
