ï‚· Failure monitoring / Fault Code Memory
o Reported Failures
 are stored in the Fault Code Memory
ï‚· Up to 20 entries
 Can lead in an ECU switch over
 Can activate the ECU caution
 Can cause a substitute function (e.g. substitute value)
ï‚· ECU Switch Over
o Reported Failures can lead to an automatic switch over
 An internal logic (Voter) selects the ECU to be active
 The Pilot can overrule the decision of the EECU
 The magnitude of power change can be up to 10%
 The typical switch over time is 10 ms.
ï‚· Diagnosis via defined CAN- Protocol possible
o AE diagnostic tool (AE 300 wizard)
ï‚· Eventrecorder and Datarecorder provided
o Eventrecorder stores defined „Events“ (e.g. reported failures, crossed limits)
o Datarecorder stores cyclically predefined values
 Time stamp based on a Real Time Clock
ï‚· Statistics
o Records statistics of 8 physical parameters
o Engine and ECU uptimes are recorded
