Engine Display if installed:
Description:
One applicable engine display system consists of a Main Engine Display (MED) and a Secondary
Engine Display (SED) device, which is offered by Austro Engine (part no. MED: A1A-10-100-000; part
no. SED: A1A-10-200-000). This system is proven to display the relevant engine parameters in
consistence with the engine operation limitations as described in the Operation Manual.
The display is approved as part of the engine installation by the airframe manufacture.
Installation, Operation and Maintenance Information:
The instructions for installing, operating and maintaining the engine displays are given in the
document A1.Apr.01 Revision 6 “Design Specification”. In this document the definition of the physical
and functional interfaces to the aircraft and aircraft equipment is given.
Display Layout, Limits and Indication:
MED Layout SED Layout
