below:
Cancel All — tap to cancel all selected parameters. Up to 50 parameters can be
selected at one time.
Show Selected/Show All — tap to switch between the two options. One displays
the selected parameters, the other displays all available items.
Graph Merge — tap to merge selected data graphs (for Waveform Graph Mode
only). This function is very useful when comparing different parameters.
NOTE
This mode supports the merging of 2 to 5 parameters from different graphs. Only
quantitative parameters are supported.
➢ To merge selected data graphs
1. Select parameters to be merged.
2. Tap the Graph Merge button at the bottom of the Live Data screen.
⚫ This mode only supports quantitative parameters that can be represented
digitally. If non-digital parameters are selected, a message will display
advising the user that the selected parameters are not supported in this
mode and to select 2 to 5 digital parameters. Tap Got It to return to the
previous screen and select supported parameters.
⚫ When unsupported parameters are selected, a message will appear
advising the user to select only supported parameters. A message will also
appear if more than 5 parameters have been selected. Please select 2 to 5
supported parameters and tap the OK button to merge.
3. Tap the Cancel Merging button at the bottom of the Live Data screen to cancel
merging.
To Top — moves a selected data to the top of the list.
Setting — tap to set recording duration: From 5 seconds to 60 minutes.
➢ To set live data recording duration
1. Tap the Setting button at the bottom of the Live Data screen.
2. Tap the “>” button to the right of Recording Time After Trigger bar and select
a time length.
3. Tap OK to save the setting and return to the Live Data Setting screen, or tap the
“x” button at the upper-right corner to exit without saving.
4. Tap Done at the upper-right corner of the Live Data Setting screen to confirm
and save the setting, and return to the Live Data screen, or tap Cancel to exit
without saving.
Clear Data — tap to clear all cached live data.
Freeze — displays a still capture of retrieved data.
