4.6.2.3 Diagnostics Report Cloud Sharing
1. Tap Data Manager > Cloud Report to enter the Report List screen.
Figure 4-20 Report List Screen
NOTE
Note that if the report displays , it means the report has been uploaded to the cloud
successfully, and you can share the report with others; if the report displays , it means
the report has failed to upload to the cloud, but will try to automatically upload to the cloud
when entering the Report again.
2. Tap the on the lower-right corner of the report.
3. There are three ways for report cloud sharing: scan the QR code, send by email,
send by SMS (via phone number).
4.7 Exiting Diagnostics
The Diagnostics application remains open as long as there is an active communication
with the vehicle. You must exit the diagnostics operation to stop all communications with
the vehicle before closing the Diagnostics application.
NOTE
Damage to the vehicle electronic control module (ECM) may occur if communication is
disrupted. Ensure all forms of communication link such as data cable, USB cable, and
wireless or wired network, are properly connected throughout the test. Exit all interfaces
before disconnecting the test cable and power supply.
