31
⚫ Previous Frame — moves to the previous frame of frozen data.
⚫ Next Frame — moves to the next frame of frozen data.
⚫ Play/Pause — tap to play/pause the frozen data.
⚫ Resume — tap to exit the freeze data mode and return to live data display.
Record — starts recording the live data of the selected data items. Tap the Record
button at the bottom of the Live Data screen. A message will display prompting user
to select parameters to record. Tap Got It to confirm. Scroll down and select data to
record. Tap the Record button to start recording. Tap the Resume button to stop
recording. The recorded live data can be viewed in the Review section at the bottom
of the Live Data screen. The recorded data can also be reviewed in the Data
Manager application.
⚫ Resume — tap to stop data recording and return to normal data display.
⚫ Flag — displays when the Record function is applied. Tap to set flags to mark
points of interest when recording data. Notes can be added during playback in
Review or Data Manager. Select the preset flag to open a popup window and
display a virtual keyboard to enter notes.
Review — reviews the recorded data. Tap the Review button to display a list of
recordings. Select an item to review.
NOTE
Only data recorded during the current operation can be reviewed on the Live Data screen.
All historical recorded data can be reviewed in Review Data in the Data Manager
application.
⚫ Previous Frame — moves to the previous frame of recorded data.
⚫ Next Frame — moves to the next frame of recorded data.
⚫ Play/Pause — tap to play/pause the recorded data.
⚫ Show Selected — displays the selected parameters.
⚫ Graph Merge — merges selected data graphs.
⚫ Back — exits the review and returns to the Live Data screen.
Back — returns to the previous screen or exits the function.
4.4.5 Active Test
The Active Test function is used to access vehicle-specific subsystem and component
tests. Available tests vary by vehicle.
During an active test, the tablet sends commands to the ECU to activate the actuators.
This test determines the integrity of the system or part by reading ECU data, or by
