AUTOFLAME Mk8 MM Installation And Commissioning Guide

7 Remote Control
Page 120 Mk8 MM Expansion Features Installation and Set-Up Guide 04.09.2016
Address Description Type
30843 Fuel 1 Start-ups Read analogue
 Start-ups
30844 Fuel 2 Start-ups Read analogue
 Start-ups
30845 Fuel 3 Start-ups Read analogue
 Start-ups
30846 Fuel 4 Start-ups Read analogue
 Start-ups
30847 Current Air Pressure Read analogue
 mbar x 10, “wg x 10
 Parameter 43 value
30849 Current Gas Pressure Read analogue
 mbar x 10, “wg x 10, PSI x 100
 parameter 41 value
32001 Capacitance Probe 1 Signal Read analogue
 Hz reading
32002 Capacitance Probe 1 Reading on MM Read analogue
 Metric: mm
 Imperial: inches x 10
32005 Capacitance Probe 2 Signal Read analogue
 Hz reading
32006 Capacitance Probe 2 Reading on MM Read analogue
 Metric: mm
 Imperial: inches x 10
32009 Alarm Status Read analogue
 0 = No alarm, 1 = Alarm
32010 Warning Status Read analogue
 0 = No warning, 1 = Warning
32012 Alarm Code Read analogue
 0 = System is not in alarm, N = alarm number
32013 Warning Status Read analogue
 0 = System is not in warning, N = warning number
32014 Steam Temperature (
O
C) Read analogue

O
C
32015 Feed Water Temperature (
O
C) Read analogue

O
C
32016 Steam Flow Rate (lb/hr) Read analogue
 lb per hour
32017 Heat to Steam Output (BTU per lb) Read analogue
 BTU per lb
32018 Feed Water Control Element Percent Read analogue
 %
32020 Sudden Pressure Drop Read analogue
 0 = Sudden pressure drop not detected, 1 = sudden pressure drop detected
