7 Remote Control
04.09.2016 Mk8 MM Expansion Features Installation and Set-Up Guide Page 121
Address Description Type
32021 Boiler Efficiency Read analogue
 %
 Returns value 0 if no heat flow function is enabled
32022 Economiser Efficiency Read analogue
 %
 Returns value 0 if no heat flow function is enabled
32023 Totalised Steam low word (lbs) Read analogue
 Total steam output = steam low word + (65536 x steam high word)
32024 Totalised Steam high word (lbs) Read analogue
 Total steam output = steam low word + (65536 x steam high word)
32025 Steam Temperature (
O
F) Read analogue

O
F
32026 Feed Water Temperature (
O
F) Read analogue

O
F
32027 Steam Flow Rate (kg/hr) Read analogue
 Kg per hour
32028 Heat to Steam Output (KJ/kg) Read analogue
 KJ per kg
32029 Totalised Steam low word (kg) Read analogue
 Total steam output = steam low word + (65536 x steam high word)
32030 Totalised steam kg high word (kg) Read analogue
 Total steam output = steam low word + (65536 x steam high word)
32037 Cold Start Status Read analogue
 0 = System not in cold start mode, 1 = system in cold start mode
32040 TDS Target Value Read analogue
 Target value in ppm or μS/cm
32041 TDS Measured Value Read analogue
 Measured value in ppm or μS/cm
32045 Current Draught Servo Angle Read analogue
 mbar x 10, “wg x 10
 Parameter 43 value
32046 Current Draught Pressure Read analogue
 mbar x 10, “wg x 10
 Parameter 43 value
32047 Commissioned Draught Pressure Read analogue
 mbar x 10, “wg x 10
 Parameter 43 value
32048 Time to Next Bottom Blowdown Read analogue
 Returns value = (hours x 100) + minutes e.g. 215 is 2 hours 15minutes
32049 Current Heat Flow Read analogue
 Metric: MW x 10
 Imperial: MMBTU/hour x 10
32050 Current Water Flow Read analogue
 Metric: Litres per second
 Imperial: US gallons per minute
