AS1635-MT-EN-03
p. 32/46
Operating mode Operating mode of the turnstile in each direction of passage:
– Controlled: Access authorisation is required before passing (by reader, push
button or Ethernet link)
– Free: The turret is unlocked in this passage direction and access is free.
– Closed: Passage is not authorised, and requests for passage are not taken into
consideration.
Standby mode – Two options are available: Normally open (NO) or normally closed (NC). As a
reminder, the NO mode is very rarely used, because its interpretation by the users
is less clear.
Enable HMI In order to enable or disable the HMI interface.
By clicking on the Help button, located to the right of each of the configuration lines, you will obtain brief information about
the parameter and the possibility of restoring the factory setting of the selected parameter:
You will always be able to undo or save the changes made on the different configuration pages.
In order to do this, the two buttons below will always be visible:
13.2. smart n’ slim
Allows you to define all the parameters related to the integration of the device in the Supervision module, or Smart n 'Slim,
developed by Automatic Systems. (For more details, refer to the Smart n 'Slim manual)
Group name Allows you to define the name of the group to which the equipment belongs.
Position in the array Allows you to set the position of the equipment in an array.
Position in the lane Allows you to determine the position of the equipment in the lane.
