Avaya 9600 Series Configuring

DJH Reviewed:
SPOC 07/08/2011
Solution & Interoperability Test Lab Application Notes
©2011 Avaya Inc. All Rights Reserved.
17 of 51
SM6-1_CMES
3.9. Administer Uniform Dial Plan
Use the change uniform-dialplan n command, where n is the first digit of the extension
numbers used for SIP stations in the system.
In the sample configuration, 5-digit extension numbers starting with “506xx” are used for
extensions associated with the 9600 Series SIP Deskphones.
Fill in the indicated fields as shown below and use default values for remaining fields.
 Matching Pattern Enter digit pattern of extensions assigned to SIP endpoints.
 Len Enter extension length.
 Net Enter “aar”.
change uniform-dialplan 5 Page 1 of 2
UNIFORM DIAL PLAN TABLE
Percent Full: 0
Matching Insert Node
Pattern Len Del Digits Net Conv Num
506 5 0 aar n
777 5 0 aar n
3.10. Administer AAR Analysis
This section provides the configuration of the AAR pattern used in the sample configuration for
routing calls between SIP endpoints and other stations. In the sample configuration, extension
numbers starting with digits “506xx” are assigned to SIP endpoints.
Note: Other methods of routing may be used.
Use the change aar analysis n command where n is the first digit of the extension numbers
assigned to SIP endpoints in the system.
Fill in the indicated fields as shown below and use default values for remaining fields.
 Dialed String Enter leading digit (s) of extension numbers.
 Min Enter minimum number of digits that must be dialed.
 Max Enter maximum number of digits that may be dialed.
 Route Pattern Enter Route Pattern defined in Section 3.7.
 Call Type Enter “unku”.
change aar analysis 5 Page 1 of 2
AAR DIGIT ANALYSIS TABLE
Location: all Percent Full: 1
Dialed Total Route Call Node ANI
String Min Max Pattern Type Num Reqd
506 5 5 50 unku n
777 5 5 10 unku n
