4.5. Define Entity Link between Avaya Aura® Session Managers
To provide redundancy and enable sessions to be alternatively routed through the second Session
Manager in the case of a network failure, define an Entity Link between Session Managers.
Expand Elements  Routing and select Entity Links from the left navigation menu.
Click New (not shown). Enter the following values.
 Name Enter an identifier for the link to each telephony system.
 SIP Entity 1 Select one of Session Managers previously defined.
 SIP Entity 2 Select second Session Manager.
 Protocol After selecting both SIP Entities, select “TCP” as the required
Protocol.
 Port Verify Port for both SIP entities is “5060”.
 Trusted Enter
.
 Notes Enter a brief description. [Optional].
Click Commit to save Entity Link definition.
The following screen shows the Entity Link defined between Session Managers in the
sample configuration.
