3.12. Verify Off-PBX-Telephone Station-Mapping
Use the change off-pbx-telephone station-mapping xxx command where xxx is an extension
assigned to a 9600 Series SIP Deskphone to verify an Off-PBX station mapping was
automatically created for the SIP station.
On Page 1, verify the following fields were correctly populated.
Application Verify “OPS” is assigned.
Trunk Selection Verify “aar” is assigned.
change off-pbx-telephone station-mapping 50655 Page 1 of 3
STATIONS WITH OFF-PBX TELEPHONE INTEGRATION
Station Application Dial CC Phone Number Trunk Config Dual
Extension Prefix Selection Set Mode
50655 OPS - 50655 aar 1
-
-
On Page 2, verify the following fields were correctly populated.
Call Limit: Verify “3” is assigned corresponding to the number of
call-appr entries assigned in Section 3.11.
Mapping Mode: Verify “both” is assigned.
Calls Allowed: Verify “all” is assigned.
change off-pbx-telephone station-mapping 50655 Page 2 of 3
STATIONS WITH OFF-PBX TELEPHONE INTEGRATION
Station Appl Call Mapping Calls Bridged Location
Extension Name Limit Mode Allowed Calls
50655 OPS 3 both all none
-
3.13. Save Translations
Configuration of Communication Manager Evolution Server is complete. Use the save
translation command to save these changes.
Note: After making a change on Communication Manager which alters the dial plan or
numbering plan, synchronization between Communication Manager and System Manager must
be completed and SIP telephones must be re-registered.
See Section 4.11 for more information on how to perform an on-demand synchronization.
