Avaya Aura - Configuring SIP Trunks for the Avaya Aura Web Gateway on System Manager

• Description: Type a description for the element.
• Node: Type the FQDN address of the Avaya Aura
®
Web Gateway server.
6. To enable SSO login, in the Access Profile section, perform the following:
a. Click New.
b. In the Application System Supported Protocol section, in the Protocol field, click URI.
c. In the Access Profile Details section, in the Name field, type a name for the access
profile.
d. In the Access Profile Type field, click EMURL.
e. In the Protocol field, click https.
f. In the Host field, type the Avaya Aura
®
Web Gateway server FQDN.
g. In the Port field, type 8445.
h. In the Path field, type /admin.
i. In the Order field, retain the default value.
j. In the Description field, type a description of the access profile.
k. Click Save.
7. Click Commit.
8. On the System Manager console, click Elements > Web Gateway to verify that the Avaya
Aura
®
Web Gateway element has been added.
Configuring SIP Trunks for the Avaya Aura
®
Web Gateway on
System Manager
About this task
The Avaya Aura
®
Web Gateway sends SIP messages to Session Manager port 5061 using TLS.
Use this procedure to ensure that Session Manager is configured to accept these messages.
Important:
For an Avaya Aura
®
Web Gateway cluster, repeat this procedure for each node in the cluster
using the respective node IP or local FQDN when required.
Before you begin
Set up your Avaya Aura
®
infrastructure, including System Manager.
Procedure
1. On the System Manager web console, click Elements > Routing > SIP Entities.
2. In the SIP Entities area, click New to create a new SIP entity for your server.
You can also edit an existing SIP entity using the Edit button.
System Manager, Avaya Aura
®
Device Services, Media Server, and Avaya Equinox Conferencing configurations
October 2018 Deploying the Avaya Aura
®
Web Gateway 100
