Related links
Connecting devices on page 43
Installing the contact closure on page 55
Installing the contact closure
Procedure
1. Follow the installation instructions in the Avaya Partner Contact Closure Adjunct Installation
Instructions leaflet to install the Contact Closure and connect the auxiliary devices that will
be activated and deactivated by the Contact Closure relays.
2. Note which device is connected to each relay.
You will need this information for configuration.
3. Connect the Avaya Partner Contact Closure adjunct box to the CC port on the Branch
Gateway front panel.
Use a 24 gauge minimum telephone wire, no longer than 200 ft, with a standard four wire
RJ-11 connector.
Related links
Avaya Partner Contact Closure Adjunct installations on page 54
Connecting devices
February 2017 Installation and Upgrades for the Avaya Branch Gateway G430 55
