DS1/T1 CPE loopback jack
Issue 9.1 June 2006 429
Figure 41: Network interface at extended demarcation point (smart jack accessible) for an
MM710 multi-media module
Figure notes:
1. Span section 1
2. Span section 2
3. Span section 3
4. G700 or G350 Media Gateway
5. E1/T1 port on an MM710
multi-media module
6. RJ-48 to network interface (up to 1000 ft. [305 m])
7. Dumb block (extended demarcation)
8. Loopback jack
9. Network interface smart jack
10. Interface termination or fiber multiplexer (MUX)
11. Central office
12. Dumb block to smart jack RJ-48
prdfcs5a KLC 080602
ALM
TST
ACT
123456 87
ALM
TST
ACT
123456 87
REMOVE
ALM
TST
ACT
OKTO
SHUTDOWN
SERVICES USB1 USB 2
E1/T1 EIA 530A DCE
ALM
TST
ACT
SIG
EISO EMSM EOSI
1 2 3
4
5
6
8
9
10
12
11
7
