Installing IP500/IP500 V2 Page 229
15-601042 Issue 28c (19 August 2013)IP Office 9.0
System Components: IP500 Base Cards
· Red/Green Fast Flash (port 9) or Green Fast Flash (port 10) = Alarm
indication signal (AIS) from the trunk remote end.
· Red with Green Blink (port 9) or Green Blink (port 10) = Port in
loopback mode (set through IP Office System Monitor).
Name
Description
SAP Code
IPO IP500 V2 EXTN CARD ETR6
IPO IP500 V2 EXTN CARD ETR6
700476039
