10.12.9 T3 DSS
The maximum number of button module buttons supported, of any type, on a single system is 1024 .
The T3 DSS provides an additional 36 programmable keys for phones in the supported T3 series. The T3 DSS is moulded
and designed to be attached to the associated phone. Signalling is achieved by cable connection to the Link port on the T3
phone. A further two T3 DSS units can be chained from the first T3 DSS. For additional limitations see Phone Add-Ons
.
Feature
Detail
Connects via
Link port on phone.
Supported by
T3 Compact, T3 Classic, T3 Comfort
Maximum per phone
3.
Maximum per DS module
-.
Additional requirements
None.
IP Office release
3.1+.
Programmable Buttons
36.
Item
Colour
SAP Code
T3 DSS Unit
Black
700380322
White
700380330
T3 DSS Expansion Unit
Black
700380348
White
700380355
