Avaya IP500 V2 - Page 305

Installing IP500/IP500 V2 Page 305
15-601042 Issue 28c (19 August 2013)IP Office 9.0
System Components: Phones
10.11.23 3810
The phone uses a wireless 900MHz digital protocol to connect to its base station. The base station connects to an IP Office
DS port. The base station also requires a power outlet socket. Additional power outlet sockets are required for the phone
charger.
This phone is supported in North America (U-Law) only. Not supported on the IP500 DS16 V2, IP500 DS30 V2, IP500
DS16B, IP500 DS30B and IP500 Combination cards.
Depending on coverage overlap, between three and five 3810s can be connected to the same IP Office.
3810
Feature
Detail
Connects via
DS port.
IP Office Release
2.1+
Programmable Buttons
4.
Headset Socket
Handsfree Speaker/
Microphone
/
Message Waiting Lamp
Upgradable Firmware
Item
SAP Code
3810 Set - Includes phone, base station, charger, belt clip and power supply units for charger and base
station.
700305105
