External Expansion Module LEDs
Module
LEDs
All
The center LED on all external expansion modules is used to indicate the overall state of
the module as follows:
· Red flashing = Module starting up/Loading firmware.
· Red on = Error.
· Green on = Module okay.
· Green flashing = Module starting up/Loading firmware (IP500 DS16A/30A module
only).
Analog Trunk 16
· None.
BRI So8
· Green On = Connected.
· Green Flashing = Activity.
Digital Station 16/30
· Green Flashing = Phone detected.
· Green On = Phone active.
Digital Station 16A/30A
· Green On = Phone detected.
Phone
· None.
