Interface Control
Issue 1 August 2010 45
Interface Control
Note:
Note:
When updating local (Craft) procedures from a touchscreen deskphone, touching
the line you want to change or the applicable softkey produces the same result as
selecting a line and pressing the applicable softkey on a non-touchscreen IP
Deskphone.
Use the following procedure to set or change the interface control value.
1. When you select INT from the Craft Local Procedure Screen, the following text displays with
a prompt to use the Right and Left navigation arrows to select a setting:
The values shown are the text strings associated with the current PHY1STAT on the
Ethernet line and the current PHY2STAT system value on the PC Ethernet line.
The PHY1STAT text strings are:
●
"Auto" when PHY1STAT = 1
●
"10Mbps half" when PHY1STAT = 2
●
"10Mbps full" when PHY1STAT = 3
●
"100Mbps half" when PHY1STAT = 4
●
"100Mbps full" when PHY1STAT = 5
●
"1000 Mbps full" when PHY1STAT = 6
The PHY2STAT text strings are:
●
"Disabled" when PHY2STAT = 0
●
"Auto" when PHY2STAT = 1
●
"10Mbps half" when PHY2STAT = 2
●
"10Mbps full" when PHY2STAT = 3
●
"100Mbps half" when PHY2STAT = 4
●
"100Mbps full" when PHY2STAT = 5
●
"1000 Mbps full" when PHY2STAT = 6
2. To change the Ethernet setting, press the Right navigation arrow to cycle through the
possible settings.
Depending on the current value, the next sequential text string is selected and displayed as
the setting. For example, if the current value is 10Mbps half (2), pressing the Right
Ethernet:
PC Ethernet:
Choice Selector
Choice Selector
