Self-Test Procedure
Issue 1 August 2010 51
Use the following procedure to set the Site-Specific Option Number (SSON).
1. When you select SSON from the Craft Local Procedure Screen, the following text displays:
where the setting is the current system value of NVSSON.
2. To change the setting, use the dialpad to enter a valid SSON value between 128 and 255.
3. Press Save to store the new setting and redisplay the Craft Local Procedure screen.
Self-Test Procedure
Note:
Note:
9600 Series IP Deskphones store two software code images in reprogrammable
non-volatile memory. The primary image, called the “big app” must be running to
perform a self-test. The backup image, called the “little app” does not support the
self-test.
Note:
Note:
When updating local (Craft) procedures from a touchscreen deskphone, touching
the line you want to change or the applicable softkey produces the same result as
selecting a line and pressing the applicable softkey on a non-touchscreen IP
Deskphone.
For self-testing, use the following procedure:
1. When you select TEST from the Craft Local Procedure Screen, the telephone displays the
following text:
2. Press Cancel to return to the Craft Local Procedure screen without testing the telephone.
Press Test to start telephone testing.
The test performs the following actions:
●
All softkeys are unlabeled.
●
Groups of no more than 13 LEDs at a time on the telephone and any attached button
modules illuminate sequentially for about a half second. Illumination starts with the upper
half of the telephone and continues through the lower half of any attached button module
in a repeating cycle.
Current setting:
New Setting:
Press Test to confirm.
