Local Administrative (Craft) Options
46 9600 Series H.323 Deskphones Release 6.0 Installation and Maintenance Guide
navigation arrow changes the value to 10Mbps full (3). If the current value is 1000Mbps full
(6), pressing the Right navigation arrow changes the value to Auto (1).
3. To change the PC Ethernet setting, select that line and press the Right navigation arrow to
cycle through the possible settings.
4. Press Save to store the new setting(s) and redisplay the Craft Local Procedure screen.
Disable/Enable Event Logging
Note:
Note:
When updating local (Craft) procedures from a touchscreen deskphone, touching
the line you want to change or the applicable softkey produces the same result as
selecting a line and pressing the applicable softkey on a non-touchscreen IP
Deskphone.
Use the following procedure to enable or disable logging of system events.
1. When you select LOG from the Craft Local Procedure Screen, the telephone prompts you to
use the Right and Left navigation arrows to select a setting and displays the following text:
where the text string is the wording associated with the current system value of
NVLOGSTAT, defined as:
●
"Disabled" when NVLOGSTAT = 0
●
"Emergencies" when NVLOGSTAT = 1
●
"Alerts" when NVLOGSTAT = 2
●
"Critical" when NVLOGSTAT = 3
●
"Errors" when NVLOGSTAT = 4
●
"Warnings" when NVLOGSTAT = 5
●
"Notices" when NVLOGSTAT = 6
●
"Information" when NVLOGSTAT = 7
●
"Debug" when NVLOGSTAT = 8
2. To change the setting, press the Right (or Left) navigation arrow to cycle through the
settings.
Depending on the current value, the next sequential text string is selected and displayed as
the setting. For example, if the current value is Alerts (2), pressing the Right navigation
arrow changes the value to Critical (3). If the current value is Debug (8), pressing the Right
navigation arrow changes the value to Disabled (0).
Log: text string Choice Selector
