Local Administrative (Craft) Options
50 9600 Series H.323 Deskphones Release 6.0 Installation and Maintenance Guide
Use the following procedure to set or change the Signaling Protocol Identifier. A valid SIG
Protocol Identifier is either 0 (default), 1 (H.323), or 2 (SIP).
Note:
Note:
Perform this procedure only if the LAN Administrator instructs you to do so.
1. When you select SIG from the Craft Local Procedure Screen, the telephone prompts you to
use the Right and Left navigation arrows to select a setting and displays the following text:
where the text string is the wording associated with the current system value of NVSIG,
defined as:
●
"Default" when NVSIG = 0
●
"H.323" when NVSIG = 1
●
"SIP" when NVSIG = 2
2. To change the setting, press the Right (or Left) navigation arrow to cycle through the
settings.
Depending on the current value, the next sequential text string is selected and displayed as
the setting. For example, if the current value is SIP (2), pressing the Right arrow changes
the value to 0 (default). If the current value is H.323 (1), pressing Right arrow changes the
value to 2 (SIP).
3. Press Save to store the new setting and redisplay the Craft Local Procedure screen.
The remainder of this procedure depends on the status of the boot and application files.
Site-Specific Option Number Setting
!
CAUTION:
CAUTION:
Do not perform this procedure if you are using static addressing. Perform this
procedure only if you are using DHCP and the LAN administrator instructs you to
do this.
Note:
Note:
When updating local (Craft) procedures from a touchscreen deskphone, touching
the line you want to change or the applicable softkey produces the same result as
selecting a line and pressing the applicable softkey on a non-touchscreen IP
Deskphone.
Sig: text string Choice Selector
