Local Administrative (Craft) Options
34 9600 Series H.323 Deskphones Release 6.0 Installation and Maintenance Guide
cursor is moved back and the field contents edited). Once content is entered that
unambiguously identifies the format of the IP address (a decimal point for IPv4, or a colon for
IPv6), the rest of the address entry is set according to that format, as specified in the bullet lists
above.
About Local Administrative Procedures
Craft procedures allow you to customize the IP Deskphone installation for your specific
operating environment. This section provides a description of each local administrative option
covered in this guide, with references to the pages on which the option appears.
Note:
Note:
For touch screen-based deskphones, simply "touching" a line or a softkey
produces the same result as selecting a line or a softkey on non-touchscreen
(button-based) IP Deskphones.
Unless otherwise prohibited using administration, an end user can view but not
change most of the parameters associated with Craft procedures. For more
information, see the applicable users guide(s).
Shown As
(this value
always
displays in
English)
Craft Procedure Purpose See
8021X Set 802.1X operational mode Set the 802.1X Operational Mode
on
page 36.
ADDR Address information
programming
Static Addressing Installation on
page 37.
AGC Enable/disable Automatic Gain
Control
D
isable/Enable Automatic Gain
Control on page 41.
CALIBRATE
SCREEN
Calibrate the touch screen Calibrating the Touch Screen on
page 40.
CLEAR Clear all values to factory
defaults
C
lear Procedure on page 41.
CONT Adjust the contrast of any
Button Modules and any
non-color deskphones
Adjusting Contrast on Button Modules
and Non-Color IP Telephones on
page 43.
1 of 2
