Local Administrative (Craft) Options
36 9600 Series H.323 Deskphones Release 6.0 Installation and Maintenance Guide
Set the 802.1X Operational Mode
Use the following procedure to set or change the operational mode.
Note:
Note:
When updating local (Craft) procedures from a touchscreen deskphone, touching
the line you want to change or the applicable softkey produces the same result as
selecting a line and pressing the applicable softkey on a non-touchscreen IP
Deskphone.
1. When you select 802.1X from the Craft Local Procedure Screen, the following text displays:
where the Supplicant line is the text string associated with the current system value of
DOTIXSTAT (802.1X Supplicant Mode operation control), defined as:
●
"Disabled" if DOT1XSTAT = 0
●
"Unicast-only" if DOT1XSTAT = 1
●
"Unicast/multicast" if DOT1XSTAT = 2
and the Pass-thru line is a text string associated with the current system value of DOT1X
(802.1X Supplicant Mode)
●
"Enabled mode" if DOT1X = 0
●
"Enabled w/Logoff" if DOT1X = 1
●
"Disabled" if DOT1X = 2
2. Select (highlight) the line you want to change, then press Change.
3. Depending on which line you selected to change, the following text displays:
where, if you selected the Supplicant line, the setting is the text string associated with the
current system value of DOTIXSTAT, or if you selected the Pass-thru line, the setting is the
text string associated with the current system value of DOTIX.
4. To change the setting, press the Right (or Left) navigation arrow to cycle through the
applicable settings.
Depending on the current value, the next sequential text string is selected and displayed as
the New setting. For example when changing the Pass-thru mode, if the current value is
Pass-thru mode, pressing the Choice Selector displays P-t w/Logoff. If the current setting is
disabled, pressing the Choice Indicator changes the new setting to Pass-thru mode.
Supplicant:
Pass-thru:
Current setting:
New Setting:
