Appendix A: Reference 75
Appendix A: Reference
This appendix provides the following:
• Utility Test Mode for Modules
• Module Specifications (Power and Weight)
Utility Test Mode for Modules
If you want to run diagnostic test on any module you can enable Utility Test mode on that module. Note that after running Utility
Test mode on a module, the module will have to be rebooted from the
Surface page on the Master Module.
To enable Utility Test mode on a module:
1 Make sure the modules are fully powered up and initialized.
2 Hold down the two switches listed below for several seconds until each of the OLEDs on that module display the Avid logo.
3 Release the enable switches and the OLEDs display tests available on that module. For example, a Fader Module will display
Main in channel 1, with System, Fader, LED, OLED, Switch, Vegas, and Exit displayed in channels 2–8.
4 Available tests are indicated by the switch directly below each test flashing blue.
5 To exit, press the flashing switch below Exit. (In all test modes, channel 8 provides Back or Exit.)
6 Press the flashing blue switch below the desired test to see choices for that mode. For example, entering Fader test mode lets you
choose
Sine, Step, Group, or Triang. OLED test mode offers Vegas.
7 Press the flashing switch below the desired test.
8 To end the test and return to the previous page of choices, press the flashing switch below Exit (channel 8).
9 After performing a Utility Test on any module, reboot each module by doing the following:
• Navigate the Touchscreen to the
Surface page.
• Tap the tested module(s) on-screen to select it.
• Tap
Reboot (at the bottom of the screen).
• After rebooting modules, touch the banner display to dismiss the alert dialog.
Accessing Utility Test Mode
Module Switches to Hold
Automation Module
Select + Swap (Attention Track)
Display Module
See “Display Module Test Mode” on page 76
Fader Module
Select + Swap (channel 1)
Knob Module
Select (channel 1) + Select (channel 2)
Master Joystick Module
Select + Swap (upper left)
Master Module
Sel + In (next to top knob on left side of Touchscreen)
Master Post Module
Attention + Link (upper left)
Process Module
Clear + Func (channel 1)
The specific tests available on each module may differ from those listed in this guide.
