Avid S6 Installation Guide78
Frame Chassis, Individual
The following table lists weights of individual chassis (including cable harnesses, but not including Rear Covers, Side Covers,
modules, PSUs, or other components). If your system includes a Producers Desk, add these weights (2x small or 2x large), plus the
weight of any module(s) and PSUs to the total weight of other chassis in your system. Note that the weights shown below do not
include Fill Panels, Inlay Module, or Compression Panels (add approximately 5 lbs/2.27 kg to each chassis weight).
Determining Total System Weight
Use the data listed in Tables 1–5 to determine the approximate total weight of your configuration.
Determine the total weight of all modules (Table 1 on page 77).
+ Determine the total weight of all Ethernet switches and PSUs (Table 2 on page 77).
+ Multiply the weight of each assembled chassis (desktop or leg frame, small or large from Table 3 on page 77) by the number
of chassis in your system.
+ Add weights of Side Covers (small or large) and legs if your system includes a Leg Frame (Table 4 on page 77)
+ If your system includes a Producers Desk option, add the approximate weight of each chassis as explained in “Frame Chassis,
Individual” on page 78.
Note that all weights are approximate, and do not include Cable Sets, S6 hardware Options, or any DAW displays or other items.
Table 5. Weights of individual chassis
Item Weight
Frame Chassis Small 6.15 lbs (2.79 kg)
Frame Chassis Large 7.30 lbs (3.31 kg)
