Factory Settings
Factory settings for map layers are as follows:
Layer
Visible
Labels
Range
Detail
Alt Filter
SUA
On
160
Hi
VOR
On
On
160
Low
Towered Apts
On
On
100
Low
NonTowered Apts
On
On
80
Med
Class A/B/C
On
100
Med
> 0
Class D
On
30
Hi
< 2000
High Obstacles
On
On
50
Med
< 1500
Low Obstacles
On
On
40
Hi
< 1500
Intersections
Off
Off
40
Hi
Victor Airways
On
On
50
Med
< 19000
Jet Airways
Off
On
50
Hi
>= 17000
VFR Waypoints
Off
Off
40
Hi
NDBs
Off
Off
50
Hi
Flight Plan
On
Non-TA Traffic
On
40
n/a
Power Lines
On
10
n/a
< 1500
Interstates
On
On
100
n/a
IFR Settings
IFR settings for map layers are the same as factory settings
except for the following changes:
Layer
Visible
Labels
Range
Detail
Alt Filter
NonTowered Apts
50
Low Obstacles
50
Intersections
On
On
30
Victor Airways
40
Jet Airways
On
NDBs
On
On
Interstates
30
VFR Settings
VFR settings for map layers are the same as factory settings
except for the following changes:
Layer
Visible
Labels
Range
Detail
Alt Filter
VOR
100
