IFD400 Series Pilot Guide
1-34 System Overview
Bezel-only Control Input
Functions
Touch screen-only Control
Input Functions
Selecting page keys (e.g.
changing the “major” pages of
FMS, MAP, AUX)
Graphical Flight Planning
(“Rubber banding”)
Changing the Primary
Navigation Source
Calling up a map page info box
Starting the Frequency List
Changing remote transponder
mode
When editing data (e.g. FMS waypoint data, chart identifiers)
using touch, virtual keyboards are displayed on the IFD. There
are several virtual keyboard layouts, including a numeric keypad,
to support the needs of the various entry fields throughout the
system.
Virtual Alpha Keyboard
