3 Quick Installation Guide
Follow the steps described in Table 1 to perform a Quick Installation of the SR1. After any
change has been performed, enter 0 as many times required to return to the Main Menu. This
will save the changes to the non-volatile RAM (for further details refer to Chapter 5).
If an incorrect value was entered, press Esc to ignore the entry.
Action Verification Reference Chapter Note
Connect the USB
Cable
Communication with
SR1
10 Install Serial over USB
driver and run hyper
terminal
Modify the
management port IP
address
7.6 Menu 3.1.
Verify DHCP is off
Modify the LAN IP
address
7.6 Menu 3.A
Verify DHCP is off
Set the IP address of
default gateway
7.6 Menu 3.E
Connect the
Management Ethernet
cable
5.7
Connect the Traffic
Ethernet cable
6.7
Ping to the Management
and Traffic interfaces to
verify connection
6.7 Verify other network
elements are properly
configured
Set RF frequency
7.4.1
Menu 1.1.1.1
Set LNB Power
7.4.1
Menu 1.1.1.F
Set 22Khz
7.4.1
Menu 1.1.1.H
Verify RF lock 7.5 RF Lock LED
Configure the MPE
filter (MAC and PID)
7.4 Menu 1.1.1.E
Verify traffic to LAN Read statistics and
Wireshark
Verify default gateway
MAC
7.6 Menu 3.G.1
Table 1 - Quick Installation
