Advanced DVB-S2 Receiver Operational Manual
SR1 Specifications
21
7
77
7 SR1 User Interface
7.1
General
The Terminal Base User Interface is managed by selecting menu items, defining values, and
saving the revisions, as follows.
Selecting Items – Press the relevant number or letter.
Setting Values – Enter the relevant value, or select from a list of options. Once the value has
been entered or selected, press Enter.
Toggle – When there are only two options for setting, selection will toggle between the two.
Save to Non Volatile Memory (NV memory or Flash memory): Press 0 to save the new
value to the non-volatile memory of the SR.
Time out: If after 30 from entering to a menu, it is not save to NV memory, a warning message
will appear
7.2
Powering Up
During power up, or after a cold reset, the Terminal displays the following text (where
Programming FPGA need to complete to 100%.):
Cortex-M3 bootloader version 1.01b14
Looking for application software...
An image found. Version 0x0105C200
Valid ? Yes
Active ? No
An image found. Version 0x0105C300
Valid ? Yes
Active ? Yes
Loaded ? Yes
A valid application software found loaded to on-chip
flash.
Checking whether upgrade mode entry is requested...No
Launching application software at 0x00005000
Programming FPGA ...
100 percent complete
