Advanced DVB-S2 Receiver Operational Manual
SR1 Specifications
22
7.3
Main Menu
This section describes the main menu, as described below.
To access the main menu:
Press 0 (for as many times as required) from any sub menu, to proceed to the main menu.
The main window is displayed:
================================================================================
SR1c Serial No. 104652 30AAC Run Time: 0:01:53
Software Version 1.05b195 Hardware Version 2.05 Firmware Version 2.02b021
RX1: Active, Not Locked
Profile 1 1480.000 MHz, Auto
RX2: Active, Not Locked
Profile 1 1600.000 MHz, Auto
================================================================================
1. Configuration
2. Status
3. Network
4. System
5. Statistics
6. ACM Client
The main menu includes the following information:
Run Time is counted since last reset.
Channel parameters are updated automatically based on received signal.
Valid Firmware version indicates FPGA programming was completed successfully.
If Firmware version indicate ‘ERROR’ then FPGA image is corrupted. See chapter
11 for more information about FPGA image management
In SR1 with single receiver, the Rx2 parameters will not be displayed
30AAB – Indicates the demodulator type – BAB is for Broadcast and AAB for
Advance. 30 for cut 3.0.
Free text describing each profile that is in use in each Rx
Es/No in DB
Note
The example above refers to SR1 with dual receivers. In case of single receiver, the 2nd
line will not appear.
