Advanced DVB-S2 Receiver Operational Manual
SR1 Specifications
31
7.5
Status Menu
From the Status menu, select the required status (channel #1 or #2):
Status
======
1. RX Channel 1
2. RX Channel 2
Selecting one of the channels displays the relevant status information. The Status display is
automatically updated every 3 seconds.
The example below shows an example of the UI when receiver #1 is locked:
RX Status 1
===========
1. Tuner Status Locked
2. Demodulator Status Locked
3. Transport Status Locked
4. Demodulator Frequency Offset -243 KHz
5. Demodulator Es/N0 16.9 dB
6. Signal Input Level -100.0 dBm
7. Demodulator BER 0.00 e-7
8. Bad Frame Count 3
9. Bad Packet Count 3
A. Demodulator Link Margin 7.3 dB
B. Modulation Order and Code Rate DVB-S2 8PSK 5/6
C. Link Adaptation CCM
D. Pilots On
E. Frame Type Normal
F. Roll Off 20%
G. FPGA Loaded
