Advanced DVB-S2 Receiver Operational Manual
SR1 Specifications
25
7.4.5 RX Channel Switch Mode
To define the RX Channel Switch Mode:
From the RX Channel Switch Configuration Management, select 1 to configure the RX Channel
Switch Mode. The RX Channel Switch Mode window is displayed:
Configuration RX Channel Switch Mode
=====================================
1. Automatic
2. Manual
Select the required option, as follows:
Automatic: Select 1 to define the channel switching to be in automatic mode
Manual: Select 2 to define the channel switching to be in manual mode.
7.4.6 Configuration RX Channel Switch Period
To define the RX Channel Switch Period:
From the RX Channel Switch Configuration Management, select 2 to configure the RX
Channel Switch Period. The RX Channel Switch Period menu is displayed:
Configuration RX Channel Switch Period
=====================================
Enter Switch Period in Seconds [20 - 120]:
Enter the required switch period in seconds (Between 20-120). :
7.4.7 Select Active RX Channel
Select the Active Channel to allow the operator to manually select the active channel when in
Single Rx Channel mode.
To define the Active RX Channel:
From the Configuration menu, select, 3. Active Rx Channel. The Select Active
Channel menu is displayed:
Select Active Channel
==================
1. Rx Channel 1 Active
2. Rx Channel 2 Not Active
Select the required option to define the active channel.
7.4.8 RX Channel Configuration Menu
The SR1 support two physical RX channels.
This manual will explain the configuration of RX1. Configuration of Rx2 is similar.
The RX Channel 1 Configuration menu enables configuring the reception, demodulation and
De-Capsulation parameters of the Rx channel.
To define the RX 1 Configuration settings:
From the main menu select, 1. Config Rx Channel 1 to define the RX Channel 1 configuration.
The RX 1 Configuration menu is displayed:
