Advanced DVB-S2 Receiver Operational Manual
SR1 Specifications
46
8.6
No Data Received by Default gateway
Data to the default gateway needs to be received, De-MPE and forwarded. Failure in any of the
phases must be verified:
RF Unlock
DE MPE filters setting: Verify the correct PID exists and that filter is active.
Default gateway: The Default gateway is not configured correctly, or does not reply to ARP..
Statistics Counters: Verify the statistics counters of the relevant filter progresses.
8.7
Management Interface does not react to Telnet, SNMP
and Ping
The Management interface may be disabled. Check Network menu
8.8
No data is received by an host on the LAN
This is different than the case described in paragraph 8.8, it refers to host other then the default
gateway.
Check that the specific host appears In the SR1 Traffic ARP table. See more in 7.6.3
8.9
No Multicast traffic from the Traffic interface
Verify in network menu, in the LAN section that multicast is enabled.
8.10
No traffic form RF received on LAN
Isolate the path of the traffic using the following
• Traffic counter in the statistics menu
• SNMP MIB-2 Interfaces counters.
The SR1 has two interfaces 1 – RGMII port where the FPGA is connected to the switch.
Interface 2 – Fast port where the CPU is connected to the switch.
Interface 1:
InOctets - counter (non-negative value) of 8-bit chunks sent out of switch port connected to
FPGA
OutOctets - counter (non-negative value) of 8-bit chunks received by switch port connected to
FPGA
Interface 2:
InOctets - counter (non-negative value) of 8-bit chunks sent out of switch port connected to
MCU
OutOctets - counter (non-negative value) of 8-bit chunks received by switch port connected to
MCU
To monitor traffic from satellite link, read the OutOctets of interface 1
8.11
SR1 indicates firmware version “error”
The meaning of “error” on the firmware version is that the SR1 application could not load FPGA
file
Check the FPGA versions menu, under FPGA upgrade menu, to verify there are FPGA files
loaded to the Flash. If the list is empty, please contact Ayecka support
