Advanced DVB-S2 Receiver Operational Manual

SR1 Specifications

7.7.12 Hardware Information Menu

The SR1 Board Hardware Information menu is displayed, as follows:

SR1 Board Hardware Information

==============================

Permanent Storage Device: Numonyx Serial Flash Memory M25PX16 16

Mbit

RX Chipset Cut/Version: TV0900 30 BAB

7.7.13 Display Running Configuration

The complete configuration is displayed on the terminal. It is recommended to save the output

of the terminal to local text file.

7.7.14 Menu Timeout

Set the time out until the user interface close the current menu and pop one up.

7.7.15 Factory Settings

For Ayecka only

7.7.16 Bootloader Upgrade

To view the Bootloader upgrade menu select F from the system.

Bootloader Upgrade

==================

1. TFTP Server IP Address 192.168.100.90

2. Filename EBLc_v1.1b14.asw

3. Show installed versions

4. Start the download procedure

5. Start the upgrade procedure

For further information refer to Chapter 11 SR1 Software and Firmware Upgrade – about

the Software Upgrade procedure.

7.7.16.1 Show Installed Versions Menu

The Show the installed version menu, enables viewing the Software images stored in the SR1

non volatile RAM:

Bootloader Versions

===================

Index Version Image Size Valid Active

1. 1.1b14
