Advanced DVB-S2 Receiver Operational Manual

SR1 Specifications

5.4

Installation Procedure

5.5

Power UP

The power up includes the following:

 Plug the DC into the SR1.

 Verify that the Power LED blinks between the Red and Green for ~15 seconds and then

remains Green.

Note: If the LED does not turn green after 15 seconds, refer to Chapter 8 - Trouble Shooting

5.6

Configuration

Configure the following parameters:

 RF frequency: For further details refer to 7.4.1.



MPE Filters: For further details refer to

8.8.4.

 Default Gateway IP Address: For further details refer to 7.6.

5.7

Cables Connection

Connect the cables to the SR1 in the following order:

 RF

 LAN

 Management

 Power

Note:

Serial management is optional. It should be used for initial configuration only.
