4.5 SR1 SNMP MIB
The SR1 SNMP MIB provides the operator an interface to configure the device, monitor it and receive
alerts (traps) on specific events. For further details on the MIB refer to Chapter 16, SNMP MIB
For the SNMP MIB of the SR1 please contact info@ayecka.com.
on page 73.
The MIB is comprised of the following sections:
 Configuration of the RX channels including the RF and MPE parts.
 A Network enabling the operator to control IP address acquisition mode (static or DHCP), Read
MAC address and more.
 A system enabling the operator to reboot the device, initiate the SW upgrade, perform a FPGA
upgrade, read serial numbers and more.
 Traffic counters – The SR1 MIB support traffic counters for two interfaces – FPGA and
Management CPU
FPGA
- InOctets – Packets sent to FPGA (ARP, Ping etc)
- OutOctets – Packets sent from FPGA (Packets from Air). These are the packets sent
out to the LAN
Management CPU
- InOctets – Packets sent to CPU
- OutOctets – Packets sent from CPU
 Alarms listing all available traps
 Demod Lock: A trap is sent when Demod lock on signal or loose lock
 Link Margin Low: When the Link margin is lower than 1db
 Link Margin High: When the link margin is higher than 3db
