Advanced DVB-S2 Receiver Operational Manual
SR1 Specifications
26
RX 1 Configuration
==================
1. Configuration Set 1 Active
2. Configuration Set 2 Not Active
3. Configuration Sets Management
Select the required option to define the Rx 1 configuration
7.4.8.1 RX Channel Configuration Sets Management
Each RX channel (Physical channel) supports two configuration sets. The selection of
configuration set can be manual or automatic.
In Automatic mode the SR1 will try to lock using one configuration set for configured period of
time. If it fails to lock, it will try the other configuration set.
The display on the main menu is updated according to the configuration set in use.
To define the RX 1 Configuration Set Management:
From the RX 1 Configuration menu, select 3. Configuration Sets Management. The Rx
Configuration Set Management menu is displayed:
RX Configuration Set Management
===============================
1. Profile Switch Mode Auto
2. Profile Switch Period 3 sec
Select the required option ,as follows:
Profile Switch Mode: Select this option to toggle between the profile switch mode
Auto or Manual
Profile Switch Period: Select this option to define the profile switch period.
When Automatic mode, the SR1 will change profile after the defined Profile Switch
period in seconds.
7.4.8.1.1 RX Channel Configuration Sets Management: Profile Switch Period
To define the RX Channel Configuration Sets Management Profile Switch Period:
From the RX Configuration Set Management menu, select 1 to configure the Profile Switch
Mode. The Configuration Profile Switch Period menu is displayed:
RX Configuration Set Management
===============================
Enter Switch Period in Seconds [3 - 30]:
Enter the required period in seconds.
