Advanced DVB-S2 Receiver Operational Manual
SR1 Specifications
29
H 22KHZ 22KHZ control to the LNB R/W On, Off
I Status In automatic selection of configuration, this
indicates if the configuration is active or not.
In manual mode this parameter set the
configuration to be active or not
R/W On, Off
J
Free text that will be presented on top menu
when the profile is in use
Table 4 - SR1 Rx channels configurable parameters
Read Only parameters are detected automatically from signal.
7.4.8.2.1 RX Channel Filters Table Menu
Filters Table configuration menu set the parameters related to the De-Capsulation filters -
PID/MAC/IP and Multicast. The Menu has 8 records. Select the relevant record by typing the
number.
The filters are common when SR1 in single demodulator mode and separated when in dual
demodulator mode.
By Default, all MAC address entries are populated with the AIR MAC of the SR1
RX Transport Filter Table
=========================
Slot PID Ethernet Address Status IP Multicast
1 601 CC-F6-7A-04-B7-44 Enabled Block
2. 501 CC-F6-7A-04-B7-44 Enabled Pass
3. 401 01-00-5E-01-01-01 Enabled Pass
4. 0 CC-F6-7A-04-B7-44 Disabled Block
7.4.8.2.1.1 RX Channel Transport Filter Record Configuration Menu
The Rx channel transport stream filters record configuration menu sets parameters of specific
filter.
Below is an example of setting filter for unicast traffic on Specific PID, with destination MAC
address as specified
RX Transport Filter Record #1:
===============================
1. PID 601
2. Ethernet Address: CC-F6-7A-04-B7-44
3. Status: Enabled
4. IP Multicast: Block
IP Multicast: Select this option to toggle Multicast enable or disabled for the filter
Status: Select this option to toggle the status of the filter Enabled or Disabled.
