Advanced DVB-S2 Receiver Operational Manual
SR1 Specifications
33
7.6
Network Menu
The Network menu configures all the networking related parameters, as follows:
Network
=======
1. Management IP Address 10.0.0.2
2. Management IP Mask 255.255.255.0
3. Management Ethernet Address CC-F6-7A-04-CE-D4
4. Management IP Multicast OFF
5. Management DSCP 0
6. Management VLAN ID 0
7. Management Default Gateway 10.0.0.1
8. Management DHCP Client ON
9. Management Port State ON
A. LAN IP Address 192.168.10.31
B. LAN IP Mask 255.255.255.0
C. LAN Ethernet Address CC-F6-7A-04-CE-D3
D. LAN IP Multicast ON
E. Router IP Address 192.168.10.101
F. LAN DHCP Client OFF
G. ARP Management
H. Air IP Address 192.168.1.161
I. Air Ethernet Address CC-F6-7A-04-CE-D2
J. Isolate Networks Isolated
The Network menu includes the following:
Management Interface: 100baseT Ethernet interface at the front of the SR1
LAN (GigE) interface: 1000BaseT Ethernet interface at the front of the SR1
Default gateway IP address: IP address of device to which SR1 forward all traffic
Management DHCP client: Determine if Management interface IP address is static or DHCP
Management DSCP: Set the DSCP value in IP traffic generated by the Management interface
Management VLAN ID: Set the VLAN value in Ethernet traffic generated by the Management
interface
Arp Configuration: Determines if the SR1 will learn the MAC address of the default router by
sending ARP or by manual configuration.
