Advanced DVB-S2 Receiver Operational Manual
SR1 Specifications
27
7.4.8.2 Active Configuration Set
To define the active RX 1 Configuration Set 1 setting:
From the RX 1 Configuration menu, Select 1 Configuration Set 1. The Configuration Set 1
menu appears showing the defined settings:
Configuration Set 1
===================
1. Tuner Frequency 1600.000 MHz
2. Tuner Acquisition Bandwidth 10.000 MHz
3. Standard DVB-S2
4. Coding Mode CCM
5. Symbol Rate Auto
6. MODCOD Auto
7. RollOff Auto
8. Pilot Auto
9. Spectral Inversion Auto
A. Gold Code 0
B. Frame Type Normal
C. Encapsulation MPEG-TS
D. ISI 0
E. Filters Table
F. LNB power Off
G. LNB compensation Off
H. 22 KHz Off
I. Status Active
J. Profile Name 100ksps signal
Note
Low Symbol Rate Configuration:
In order to lock on the signal with a symbol rate of 1 Msps or lower it is required to
explicitly configure the symbol rate value and an appropriate acquisition bandwidth via
the Configuration menu.
In order to cancel the manual symbol rate configuration and enable the SR1 to auto-
detect the symbol rate, the symbol rate value in the Configuration menu should be
explicitly annulled. The symbol rates that are higher than 1 Msps can be auto-detected
by the SR1.
