Advanced DVB-S2 Receiver Operational Manual
SR1 Specifications
30
The example below describes how to set the filter pass all multicast traffic on a specific PID
Note:
When setting the filter for multicast only, the Ethernet address has no meaning. The filter will
pass all Multicasts.
RX Transport Filter Record #2:
===============================
1. PID: 203
2. Ethernet Address: D1-51-4C-9C-90-00
3. Status: Active
4. IP Multicast: Pass
The example below shows setting the filter to pass only multicast traffic with a destination IP
address of 225.1.1.1 on a specific PID. The Multicast address of 225.1.1.1 is translated to the
multicast MAC address of 01-00-5E-01-01-01
RX Transport Filter Record #3
==============================
1. PID 401
2. Ethernet Address 01-00-5E-01-01-01
3. Status Enabled
4. IP Multicast Pass
