Advanced DVB-S2 Receiver Operational Manual
SR1 Specifications
15
Interface Description Type / Range
Power LED Indication LED, indicating availability of
DC power to the SR1 and Firmware
programming state.
Red - at the very SR1 startup after the
power has been applied. The constant
red coloring indicates that SR1
application software has been
launched.
The LED will stay red until the SR1
starts loading the Firmware, or in case
of a fault in Firmware loading.
Red/Green Blinking - During
Firmware programming process,
which generally lasts for 5-8 seconds.
If the Firmware programming fails, the
led will turn red again.
Green - The led turns green constantly
after two conditions are met:
The SR1 application software has
been successfully launched
AND
The Firmware has been successfully
programmed.
DC in DC power input to the SR1 12VDC, 2A
Table 2 - SR1 Front Panel Interfaces
