Advanced DVB-S2 Receiver Operational Manual
SR1 Software and Firmware Upgrade
60
To start the upload procedure:
1.
Select 4.Start the upload procedure, the SR1 requests confirmation, as follows: FPGA
Upgrade - Are you sure (Y/N)?
2.
Click Y. The SR1 formats the storage area, and the following is displayed. Formatting
Permanent Storage...
The TFTP process will then be initiated.
3.
After completion of the TFTP process, select 3. Show installed versions to view the new
file. The following is displayed:
FPGA Versions:
==============
Index Version Image Size Valid Active
1. 2.2b10 380116 Yes Yes
2. 4.1b2 248096 Yes No
Note
TFTP FPGA file does not load the file to the FPGA, it only load it to the memory on board.
To select the active FPGA image for the next boot:
• Select the required version. The following is displayed:
Version: 2.2b10, Size: 380116, Valid: Yes Active: Yes
=============================================
1. Active
2. Not Active
• Select 1. Active to activate the version. The active FPGA image will be loaded to the
FPGA only at the next cold reboot or power cycle.
Note:
• In Ayecka ftpd32 - (http://tftpd32.jounin.net/) is used.
• The SR1 TFTP client complies with TFTP (Revision 2) defined by IETF RFC 1350.
• The image file is provided by Ayecka.
• The upload process can take up to 20 sec.
