Advanced DVB-S2 Receiver Operational Manual
SR1 Software and Firmware Upgrade
65
To start the upload procedure:
4.
Select 4.Start the upload procedure, the SR1 requests confirmation, as follows:
Bootloader Upgrade - Are you sure (Y/N)?
5.
Click Y. The SR1 formats the storage area, and the following is displayed. Formatting
Permanent Storage...
The TFTP process will then be initiated.
6.
After completion of the TFTP process, select 3. Show installed versions to view the new
file. The following is displayed:
Bootloader Versions
===================
Index Version Image Size Valid Active
1. 1.1b14 15388 Yes Yes
Note
TFTP BootLoader file does not in use, it only load it to the memory on board.
To select the active BootLoader image for the next boot:
• Select the required version. The following is displayed:
Version: 2.2b10, Size: 380116, Valid: Yes Active: Yes
=============================================
1. Active
2. Not Active
• Select 1. Active to activate the version.
Once the Bootloader is loaded and selected – start the upgrade process by selecting 5. Start
the upgrade procedure.
The new BootLoader will be used at next reboot
Note:
• In Ayecka ftpd32 - (http://tftpd32.jounin.net/) is used.
• The SR1 TFTP client complies with TFTP (Revision 2) defined by IETF RFC 1350.
• The image file is provided by Ayecka.
• The upload process can take up to 20 sec.
• During Upgrade process of software or BootLoader, the FPGA image may be erased
